Musicbook Source II Network Music Player
Lindemann Musicbook Source II Network Music Player
The Musicbook Source II by Lindemann is an upgrade to the multi-award-winning original. It is a very versatile device, capable of playing the highest resolution music from a server or all the best streaming services due to its in-built DAC. You also have the ability to turn the Musicbook Source II into a high-class CD player by opting for the built-in CD drive or simply connecting an external CD drive via the USB input.
What Lindemann say
A fully equipped signal source which sets a new sound benchmark?
Here you are: the Musicbook SOURCE II is a versatile signal source that meets even the highest demands on sound quality. Be it music from streaming services or from a music server, from CDs or LPs, everything’s possible and easy to operate via the app. Friends of high-class headphones will also get their money’s worth: the integrated headphone amplifier defines new standards in this class. The icing on the cake is the excellent phono MM input for turntables!
Connect your Musicbook Source to a suitable power amplifier such as the Musicbook Power or directly to active loudspeakers, and from now on you’ll be enjoying music in the most beautiful way, rich in detail and yet relaxed, with a wide stage or a small ensemble, dynamically vigorous or soft and emotional.
Streaming 4.0 makes it possible. The new LINDEMANN streaming platform offers music playback from the internet in high-res quality with 24-bit resolution. And all that wireless via WLAN. Owing to WPS the connection to the router is a piece of cake. The ARM-core high-performance processor and the web update feature make the platform absolutely future-proof.
Technologically the Musicbook SOURCE is far ahead of the competition: all digital input signals are converted into DSD, a highly appreciated data format among audiophiles all over the world. This completely new approach raises in particular "normal" CD grade recordings to an exceptionally high sound quality level.
|The headphone amplifier of the Musicbook SOURCE has a powerful output stage which can drive headphones from 16 to 200 ohms. Owing to class-A mode, the high damping factor and ultra-short signal paths in the device the sound quality is beyond any doubt.|
|Optionally the Musicbook SOURCE is also available with a built-in CD drive (at an extra charge). The quality of the integrated D/A converter turns the Musicbook SOURCE into an absolute top-level CD player. Discover how much sound is really hidden on your CDs!|
A special highlight is a multi-room feature which allows running several streaming devices in different rooms simultaneously or individually. Convenient controlling is provided by the LINDEMANN app.
The LINDEMANN app is available for Android and iOS, both for smartphones and tablets in landscape mode. The album-oriented programming excels by a fluent browsing and an easy, intuitive operation. The app allows controlling all functions and settings of the Musicbook SOURCE.
Via USB the Musicbook SOURCE supports the connection of external CD-ROM drives and thus transforms easily into a top-class CD player without high costs! And this, of course, plug-and-play; the drive is automatically recognized and integrated via the LINDEMANN app. Control and CD text support included.
The Bluetooth function of the Musicbook SOURCE enables direct wireless music playback from smartphones or tablets (without a network). Here the A2DP Bluetooth audio transfer protocol guarantees ultimate sound quality.
The phono MM preamp of the Musicbook SOURCE has been derived from our well-known Limetree PHONO and offers an exceptional sound quality from vinyl records. The input is very low-noise and can also be driven by high-output MC-systems. The sensitivity is adjustable via the app.
Two digital SPDIF inputs allow to connect digital sources like e.g. CD drives.
Two analogue line inputs allow connecting sources like TV, tuner or tape recorders.
The IR remote control, which is included in the delivery, allows not only to set the volume level, but also to navigate through playlists or on a CD.
The Lindemann app
All functions of the Musicbook SOURCE can be controlled conveniently via the newly developed LINDEMANN app which is available for Android and iOS, for tablets also in the particularly lucid landscape mode. The app offers an easy to understand and intuitive control over the various sources. A comprehensive menu for the device settings makes the operation of the Musicbook as easy as 1-2-3.
The integrated multi-room function allows running several streaming devices in different rooms simultaneously or individually.
The supply of streaming services is broadly diversified, with a clear focus on streaming in high-res quality. Make your choice between TIDAL, Qobuz, Deezer, and HighResAudio. Furthermore, besides internet radio, there are also podcasts from a large range of providers.
The optionally available remote control made of high-quality aluminium offers all basic functions of the Musicbook and also gives you quick access without opening the app.
All functions of the Musicbook SOURCE II can be controlled conveniently via the newly developed LINDEMANN app which is available for Android and iOS, for tablets also in the particularly lucid landscape mode. The app offers an easy to understand and intuitive control over the various sources. A comprehensive menu for the device settings makes the operation of the Musicbook as easy as 1-2-3. The integrated multi-room function allows to run several streaming devices in different rooms simultaneously or individually. The supply of streaming services is broadly diversified, with a clear focus on streaming in high-res quality. You can choose between Spotify Connect, TIDAL Connect, Qobuz, Deezer and HighResAudio. In addition to internet radio there are also podcasts from lots of different providers.
All relevant functions can also be controlled with the included remote.
The circuitry of the Musicbook SOURCE II has been designed around the high-performance streaming platform and fine-tuned for optimum sound quality.
In the digital-analog converter of the Musicbook SOURCE we use one of the best-sounding converter elements of all times, the AK4493 from the Japanese digital specialist AKM. This converter excels metrologically by extremely low distortion figures and musically by natural timbres, a perfect timing and a totally relaxed pace. The converter blocks are run in mono mode, i.e. each channel has its own D/A converter. But there is more! Prior to the actual conversion, all digital input signals are submitted to an ultra-precise re-sampling by means of an MEMS femto-clock. The thus generated data are absolutely jitter-free: the basic prerequisite for perfect sound with digital music! An additional improvement offers the possibility to convert all data into a 1-bit signal (DSD).
From a musical point of view, this mode of operation is the icing on the cake and opens up a totally new sound dimension in terms of room imaging and high-frequency reproduction.
The analog preamp of the SOURCE II uses a purely analog volume level control. Analog sources are processed on the analog domain. The built-in phono MM preamp offers an exceptionally musical reproduction and is identical in construction to the highly appreciated Limetree Phono. The headphone amplifier of the Musicbook also brings you sound at its finest and has plenty of output power even for demanding headphones.
The power supply of the Musicbook sets new benchmarks for an interference- and noise-free performance. All functional areas are equipped with proprietary, ultra low-noise voltage regulators with less than 10 µV of noise voltage. Therefore a mutual influence between the Musicbook’s individual elements can be ruled out.
Sublime Sound Quality
Primarily decisive for the sound of a digital component is the digital/analog converter. For this reason LINDEMANN is breaking all new ground with the Musicbook SOURCE.
In the DSD mode all digital input signals – irrespective of the source – are converted into a high-resolution 1-bit signal (DSD 256) by means of a re-sampling process based on delta-sigma conversion. The resolution is 256 times higher than with the CD. By a simple filtering in the converter blocks, this signal is converted directly into an analog signal – without any interference from digital filters or a digital volume control. We completely do without digital signal processors (DSP) and their negative impact on the sound. Filtering and level control take place on a purely analog domain. The music signal obtained by this “deconstruction“ of the converter is totally transparent: highest resolution, brilliant timbres, unlimited dynamics and a new, absolutely "genuine" atmosphere that will remind you of analog reproduction!
- Measurement conditions: 22 °C, 230 V mains voltage, Audio Precision AP2722
- Mains connection: 90 – 240 V, 50 – 60 Hz
- Power consumption: 0.2 W stand-by, 8 W operation, 18 W max.
- Dimensions (W x H x D): 280 x 220 x 63 mm (11 x 8.7 x 2.5 in.)
- Weight: 2.6 kg (5.73 lbs)
- Resolution: 768 kHz/32 bit and DSD 512
- Dynamic range: >125 dB
- THD & Noise: <0.001 % (@ 0 dB FS)
- Master-Clock: Ultra low jitter MEMS Femto Clock
- Re-Sampling: with 180 dB dynamics and 32 bit resolution, bit-perfect or DSD
- Re-sampling jitter damping: >60 dB
- Converter architecture: two AK4493 DACs in dual differential mono mode, AK4137 re-sampler
- Output voltage: 3 V @ 0 dBFS RCA, 6 V @ 0 dBFS XLR
- Ethernet: 100 Mbit/s
- WLAN: Dual-band 802.11a/b/g/n/ac, WPS support
- Bluetooth: 4.2, A2DP
- USB: High-speed host interface for harddisks, USB sticks, DVD ROM drives, max. output current 1.5 A
- Supported codecs: WAV, FLAC, AIFF, ALAC, MP3, AAC,
- Ogg Vorbis, WMA, DSD
- UPnP and DLNA support
- PCM resolution: 44.1 kHz up to 384 kHz, 24bit (WLAN up to 192 kHz)
- DSD resolution: DSD 64 up to DSD 256 (WLAN up to DSD 128)
- Gapless playback
- Streaming services: TIDAL, Qobuz, Deezer, HighResAudio, Spotify
- Internet radio and podcast
- Roon Ready
- Inputs: two analog line inputs with 50 kOhms of input impedance.
- Max. input voltage 3 V unbalanced. MM input for connecting a turntable. Connection values MM: 47 kOhms / 150 pF.
- Outputs: one balanced and one unbalanced output. The outputs may be used independently. Output impedance: RCA: 100 ohms, XLR: 100
- Ohms. Max. output voltage: 3 V unbalanced, 6 V balanced
- Volume level control range: 0 to 80 dB in 1 dB steps
- Balance control: + / - 6 dB in 1 dB steps
- Frequency response: 2 – 200 kHz (-3 dB)
- THD & Noise: < 0.001 % @ 3 V output
- Headphone connector: 6.35 mm (1/4“) jack socket
- Headphone gain: 0 dB / 12 dB switchable
- Recommended headphone impedance: 16 - 200 ohms
- Damping factor of headphone output: >100
Please note: there may be a longer lead-time if you choose to purchase the optional built-in CD player
For the development of their products, Lindemann can fall back on a wealth of experience gathered in 25 years of building loudspeakers, amplifiers and digital sources. At Lindemann, new products are created by means of the most advanced design tools and measuring methods. In doing so, they use, of course, the latest and best technologies on the market. Yet the sonic outcome is always of prime importance; their ears are the key measuring instrument!
A careful optimization of all circuit details and a target-oriented selection of top-grade parts build the basis for every genuine high-end product. It takes a lot of meticulous work at Lindemann to understand all sound influences and optimize the result accordingly. On the highest level real progress in sound quality can only happen through a deep insight into the correlations and a consistent implementation in the circuit design.
Lindemann products are developed by a passionate and experienced team of engineers in Germany and made exclusively by ISO-certified firms all over Europe to meet the high quality demands of their customers. Prior to packaging and shipping, every single device is put to a thorough final inspection.
But above all stands the passion for music and well-engineered technology. Only when merged this way the result are products that are entirely convincing.
Fidelity (Germany) / February 2020
"Everything has been implemented in a completely intuitive and self-explanatory way. So much that we had to ask ourselves why all other manufactures are incapable of supplying apps of a similar standard."
